| Overall dimensions: | 1.150 mm X 1.500mm X H2.650mm |
| Minimum workable dimensions: | 130 x 130mm |
| Maximum Spacer Length with open profile: | 4.000mm |
| Minimum workable thickness: | 6 mm |
| Maximum workable thickness: | 27 mm |
| Maximum working height: | 3.080 mm |
| Minimum working height: | 1.580 mm |
| Shaped: | Yes |
| Butyl load capacity: | 1 kg block of butyl: |
| Salt transfer from 200 L drum: | closed-loop vacuum pump: |
| Drilling – Loading – Butyl | 2 independent Left–Right heads |
| Salt flow control | Fiber optics / time-based: |
| Butyl temperature control: | By touch screen |
| Machine standby management: | Automatic, set via touchscreen |
| Machine warm-up time | 40/50 min |
| Standard power supply | 400 V – 50Hz3Ph + Heart+ Neutral |
| Installed power: | 2 kW |
| Minimum operating pressure | 7/8 bar |
| Weight: | 400Kg |
Available soon…
Available soon…
Available soon…
Disponibile a breve…
Fill out the form on the side, we will reply as soon as possible, or contact us by phone.
